The designations B-47C and B-47D were applied to special variants that never went into production (described later), and so the next production version of the B-47 was the definitive B-47E.
The first B-47E flew on 30 January 1953. Four "blocks" or "phases" of the B-47E were built, each incorporating refinements on the previous block, and also sometimes featuring production changes within a block. Older blocks were generally brought up to the specifications of later blocks as they were introduced. The B-47 also incorporated the production model with the radar controlled rear tail turret.
Early production "B-47E-Is" also known featured J47-GE-25 turbojets with 5,970 lbf (27 kN) thrust, but they were quickly changed to J47-GE-25A engines, which featured a significant improvement in the form of water-methanol injection. This was a scheme in which a water-methanol mix was dumped into the engines at takeoff, increasing mass flow and so temporarily kicking the thrust up to 7,200 lbf (32 kN). Methanol was apparently added to the water as an anti-freezing agent. The engines left a trail of black smoke behind them when water-methanol injection was on.
Jet-Assisted Take Off or JATO modifications were performed on early B-47E-Is. They had the 18 built-in JATO bottles, and were quickly exchanged for an external, jettisonable "split V" or "horse collar" rack fitted under the rear fuselage. The rack carried 33 JATO bottles, in three rows of 11 bottles. The built-in JATO system was eliminated because of worries about having the JATO bottles so close to full fuel tanks, and in any case once the rocket bottles were exhausted they were just dead weight. The racks were expendable, and were dropped over specific range areas after takeoff.
The internal fuel capacity of initial production B-47Es was cut to 14,627 gal (55,369 l) as a weight-saving measure. This was considered acceptable because of the use of the big external tanks and the fact that the USAF had refined mid-air refueling to the point where it could be relied upon as a standard practice.
One welcome change in the B-47E relative to the B-47B was the return of the ejection seats, the Air Force senior leadership having reconsidered the earlier decision to delete them. In addition, the twin .50 in guns (12.7 mm) in the tail turret were replaced with twin 20 mm (0.79 in) cannon to provide more firepower, backed up by an A-5 FCS in early production and an MD-4 FCS in later production.
A final change in the B-47E was that most of the windows in the nose were deleted, with only one left on each side. However, many pictures of B-47Es show them with the full set of windows used on the B-47B. Whether the number of windows varied through B-47E production, or whether these were B-47Bs updated to B-47E specification, is unclear.
Eén uitvoering mogelijk;
- USAF, SAC
Afmetingen:
- Lengte 471mm
- spanwijdte.491mm.
Aantal onderdelen: 166
